Inqmega\Shiwojia HD 720P Smart Home Wifi Video Low Power Consumption PIR Sensor Wireless Doorbell Camera

FOB Reference Price:Get Latest Price
$12.90 - $24.90 / Pieces | 1 Piece/Pieces (Min. Order)
Type:
Smartphone
Lead Time:
Quantity(Pieces) 1 - 100 >100
Est. Time(days) 10 Negotiable
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
woshijia
Model Number:
IL-WD011
Camera:
Wifi Video Low Power Consumption PIR Sensor Wireless Doorbell Camera
Resolution:
1080*720
Power:
Ultra-low Power Consumption
night vision:
10 meters
APP:
TOSEE
visual Angle:
166°
IR leds:
six 850 - nm 28 mil high power infrared lamp
PIR:
movtion sensor
Packaging of products:
Special Export Box
Product certification:
CE,FCC,ROHS,ISO
Supply Ability
Supply Ability:
50000 Piece/Pieces per Week
Packaging & Delivery
Packaging Details
standard package
Port
shenzhen or hongkong
Lead Time :
Quantity(Pieces) 1 - 100 >100
Est. Time(days) 10 To be negotiated

Inqmega\ShiwojiaHD 720P Smart Home Wifi Video Low Power Consumption PIR Sensor Wireless Doorbell Camera

Data Sheet



                      outdoor unit             indoor unit



name

Wireless video to the doorbell

describe

 features

wireless connection,Ultra-low power consumption,Remote active awakening,Quick start

use

Guests will be able to make video voice calls and take short videos. The owner will not need to open the door to know the information

Wake up the way

The doorbell button awakens,PIR body detection wake up,Mobile phone call

Alarm push

Push for 1 second

operating system

Number of users online

Multiple users are online simultaneously

Dynamic DNS

Bring your own dynamic domain name

processor

A powerful, high-performance, programmable media HiSilicon processor with built-in ARM926 @max. 440MHz and high-speed video coprocessor

collect

CCD

1/4 inch 720p scan CMOS sensor

Sensor performance

Support automatic white balance, automatic gain control, automatic backlighting compensation

SNR

≥39dB

LUX

0.8Lux/F1.4(Color pattern),0.3Lux/F1.4(Black and white pattern)

Lens/visual Angle

1.7mm@F2.4/166°

LED

Double filter automatic switching, six 850 - nm Φ 28 mil high power infrared lamp, night vision 10 meters

IR control

IR opens night vision,Automatic detection of infrared and ICR;IR shuts the night vision function off the infrared and the ICR is fixed in daily viewing mode

video

Compression standard

H.264 Main Profile/H.264 Baseline Profile/MJPEG/JPEG Baseline

Video coding

More stream:720P/24fps+VGA/30fps+QVGA/30fps+720P @1fsJPEG snap

resolution

1080*720

audio

input

1 channel built-in - 48dB microphone

output

Built-in speaker (8 Ω 1 w)

interphone

Two - way voice - speak, bring back the echo cancellation

Compression standard/ code rate

ADPCM/32kbps

network

Network protocol

TCP/IP,HTTP,TCP,UDP,SMTP,FTP,DHCP,DNS,DDNS,NTP,UPnP,RTSP,P2P

wireless network

802.11b/g/n

Wireless network security

WPS Security encryption

wireless connection

One-button WIFI configuration

video

Video mode

Mobile detection video, doorbell button trigger video, manual video

storage

The TF card stores the maximum support for 32gb

other

power

Battery power supply two section 18650 core international general

Power consumption

Standby current 250 uA working current 170MA

work environment

Working temperature:  - 10 ~ 50 ℃, humidity is < 95%

installation

Door wall mounting

material

ABS

Product size

7.5cm*3.3cm*17.4cm  Long * width * height

product weight

330g No battery

Packing size

18.2cm*10.5cm*6.5cm
